Yardney Multi-Media filters are designed for enhanced water quality filtration for the removal of organic and inorganic suspended solids down to 5 microns. Multi-Media filters may be used as a stand-alone system or in conjunction with or as a pretreatment for other filtration technologies. The Multi-Media filtration systems utilize a vertical side shell depth of 60" with accompanied reverse stacked medias for progressive filtration through the filtration system. All Yardney industrial media filters utilize our simple backwash system for ease of operation and consistent water quality.



Yardney industrial filtration systems are shipped as a complete, finished, assembled and packaged unit. Each system is skid mounted with tanks, valves, manifolds, controller, tubing, electrical solenoids and removable underdrain assembled and ready for water source and power hookup.



Performance levels can be modified to remove suspended solids of a given size range consistent with desired application objectives.

Applications



• Removal of organic and/or inorganic suspended solids down to 5 microns with enhanced solids capacity vs. single media sand filtration

• Storm water runoff, industrial process water, incoming plant water, waste water clean-up, industrial water for plant reuse

• Pre-filtration in applications such as granular activated carbon, reverse osmosis, cartridge or bag filtration and deionized water

• 100 psi standard operating pressure (high pressure systems available)

• Flow ranges from 10 gpm and up



Advantages



• State of the art fabrication provides added strength under pressure and long system life

• ASME code shaped head construction for durability and safety

• Stainless steel wedge-wire under-drain

  • Ensures structural integrity in the harshest conditions

  • Hydraulically balanced to increase effectiveness of backwash while reducing flush frequency and waste of water

  • High strength stainless steel wedge-wire will withstand a collapse pressure in excess of 600 psi

• Standard carbon steel products use 3/16" thick material

• Backwash automatically initiated by elapsed time, pressure differential or time stamp with Synergy controller

• Easy-entry lid closure with weld tabs for operator safety

• Available in welded carbon steel

• 3M Scotchkote® 134 fusion bonded epoxy coating on interior surfaces

• Made in USA



Standard Assembly Includes



• Fully assembled for easy installation

• Skid mounted

• Backwash Valves

• Inlet, outlet and backwash manifolds

• Controller, solenoids, electrical wire, tubing

• Removable under-drain

• 3M Scotchkote® 134 fusion bonded epoxy coating on interior surfaces

Yardney Granular Activated Carbon (GAC) filtration systems use the absorptive qualities of the media to remove highly dispersed compounds from water sources too small for the removal with standard multi-media filtration technology. These automatic filtration systems are extremely effective in removing chlorine and chlorine related compounds, organic chemicals, tastes and odors, halogenated organic compounds, hydrocarbons and other highly dispersed contaminants. Yardney GAC filtration systems utilize a vertical side shell depth of 72 inches. All Yardney industrial media filters utilize our simple backwash system for ease of operation and consistent water quality. The Yardney automatically controlled filter systems operate for extended periods of time prior to a short backwash cycle.



Yardney industrial filtration systems are shipped as a complete finished assembled and packaged unit. Each system is skid mounted with tanks, valves, manifolds, controller, tubing, electrical solenoids and removable under-drain assembled and ready for water source and power hookup.



Performance levels can be modified to remove suspended solids of a given size range consistent with desired application objectives.

Applications

• Removal of chlorines, organic chemicals, taste and odor, halogenated organic compounds, hydrocarbons or other highly dispersed contaminants

• Polishing filter for contaminants not removed by other filtration systems

• 100 psi standard operating pressure (high pressure systems available)

• Flow ranges from 5 gpm

Advantages

• State of the art fabrication provides added strength under pressure and long system life

• ASME code shaped head construction for durability and safety

• Stainless steel wedgewire underdrain

  • Ensures structural integrity in the harshest conditions

  • Hydraulically balanced to increase effectiveness of backwash while reducing flush frequency and waste of water

  • High strength stainless steel wedgewire will withstand a collapse pressure in excess of 600 psi

• Standard carbon steel products use 3/16" thick material

• Backwash automatically initiated by elapsed time, pressure differential or time stamp with Synergy controller

• Easy-entry lid closure with weld tabs for operator safety

• Available in welded carbon steel

• 3M Scotchkote® 134 fusion bonded epoxy coating on interior surfaces

• Made in USA



Standard Assembly Includes



• Fully assembled for easy installation

• Skid mounted

• Backwash Valves

• Inlet, outlet and backwash manifolds

• Controller, solenoids, electrical wire, tubing

• Removable under-drain

• 3M Scotchkote® 134 fusion bonded epoxy coating on interior surfaces
